Your Location:Home >Products >25134-21-8


  • Product NameMethyl-5-norbornene-2,3-dicarboxylic anhydride
  • Purity99%

Product Details

Quick Details

  • CasNo: 25134-21-8
  • Purity: 99%

25134-21-8 Properties

  • Molecular Formula:C10H10O3
  • Molecular Weight:178.20
  • Appearance/Colour:clear light yellow oily liquid
  • Vapor Pressure:5 mm Hg ( 120 °C)
  • Refractive Index:n20/D 1.506(lit.)
  • Boiling Point:326.1 °C at 760 mmHg
  • PKA:4.42[at 20 ℃]
  • Flash Point:157.1 °C
  • PSA:43.37000
  • Density:1.302 g/cm3
  • LogP:0.89820

25134-21-8 Usage

Chemical Properties

clear light yellow oily liquid


Methyl-5-norbornene-2,3-dicarboxylic anhydride is used as a curing agent in epoxy resins and in the preparation of vertically aligned and penetrated carbon nanotube/polymer film. It serves as an intermediate in polyesters, alkyd resins and plasticizers. It is also used in electrical laminating and filament-winding. Further, it is used in the preparation of methyl nadimides endcapped resins based on tris(3-aminophenyl)phosphine oxide. It is utilized in the flame retarding treatment.

General Description

additional information see 45359 Epoxy Embedding Medium kit

Flammability and Explosibility


Purification Methods

Purify the anhydride by thin layer chromatography on Al2O3 (previously boiled in EtOAc) and eluted with hexane/*C6H6 (1:2) then recrystallise it from *C6H6/hexane. The free acid has m 118.5-119.5o. [Miranov et al. Tetrahedron 19 1939 1963, Beilstein 17/11 V 199.]
