1060735-14-9

  • Product Name9-Phenyl-9h,9'h-[3,3']bicarbazolyl
  • Molecular FormulaC30H20N2
  • Molecular Weight408.5
  • Purity99%
Inquiry

Product Details

Quick Details

  • CasNo： 1060735-14-9
  • Molecular Formula： C30H20N2
  • Purity： 99%

Good Quality Pharmaceutical Grade 9-Phenyl-9H,9'H-[3,3']bicarbazolyl 1060735-14-9

  • Molecular Formula:C30H20N2
  • Molecular Weight:408.502
  • Boiling Point:685.6±37.0 °C(Predicted)
  • PKA:17.10±0.30(Predicted)
  • PSA：20.72000
  • Density:1.23±0.1 g/cm3(Predicted)
  • LogP:8.08520

9-Phenyl-9H,9'H-[3,3']bicarbazolyl(Cas 1060735-14-9) Usage

Description 9-Phenyl-9H,9'H-[3,3']bicarbazolyl, a unique organic compound with two carbazole rings linked by a phenyl group, exhibits distinct chemical and physical properties. 9-Phenyl-9H,9'H-[3,3']bicarbazolyl has significant applications in organic electroluminescent elements, particularly in phosphorescent organic EL devices, due to its excellent hole transport capabilities and suitability as a phosphorescence host material in OLEDs. 9-Phenyl-9H,9'H-[3,3']bicarbazolyl is synthesized through a meticulous multi-step process with high yield and simplicity in post-processing, making it suitable for industrial production. Overall, 9-Phenyl-9H,9'H-[3,3']bicarbazolyl represents a significant advancement in materials science and organic electronics, contributing to the development of highly efficient and durable lighting and display technologies.

Application

9-phenyl-3,3’-bicarbazolyl is the intermediate to synthesis electronic materials, such as OLED.9-phenyl-3,3’-bicarbazolyl is a kind of organic electroluminescent materials to make OLED display screen, and this intermediate can be used in OLED series, such as Thiophene series, Fluorene series, Boronic Acid series and so on.

Isomeric SMILES: C1=CC=C(C=C1)N2C3=C(C=C(C=C3)C4=CC5=C(C=C4)NC6=CC=CC=C65)C7=CC=CC=C72
InChIKey: GKTLHQFSIDFAJH-UHFFFAOYSA-N
InChI: InChI=1S/C30H20N2/c1-2-8-22(9-3-1)32-29-13-7-5-11-24(29)26-19-21(15-17-30(26)32)20-14-16-28-25(18-20)23-10-4-6-12-27(23)31-28/h1-19,31H

1060735-14-9 Relevant articles

Efficient blue/white phosphorescent organic light-emitting diodes based on a silicon-based host material via a direct carbon-nitrogen bond

Xie, Yue-Min,Cui, Lin-Song,Liu, Yuan,Zu, Feng-Shuo,Li, Qian,Jiang, Zuo-Quan,Liao, Liang-Sheng

, p. 5347 - 5353 (2015)

A new host material BCz-Si for blue and ...

Constructing diazacarbazole-bicarbazole bipolar hybrids by optimizing the linker group for high efficiency, low roll off electrophosphorescent devices

Lv, Xialei,Wang, Bo,Tan, Jianghong,Huang, Zhi,Zhang, Qing,Xiang, Songpo,Liu, Wei,Zhuang, Shaoqing,Wang, Lei

, p. 54 - 62 (2017)

A series of novel bipolar host materials...

Blue thermally activated delayed fluorescent emitters having a bicarbazole donor moiety

Kim, Hyeong Min,Choi, Jeong Min,Lee, Jun Yeob

, p. 64133 - 64139 (2016)

Bis(4-(9′-phenyl-9H,9′H-[3,3′-bicarbazol...

A dicarbazole-triazine hybrid bipolar host material for highly efficient green phosphorescent OLEDs

Chang, Chih-Hao,Kuo, Ming-Cheng,Lin, Wei-Chieh,Chen, Yu-Ting,Wong, Ken-Tsung,Chou, Shu-Hua,Mondal, Ejabul,Kwong, Raymond C.,Xia, Sean,Nakagawa, Tetsuya,Adachi, Chihaya

, p. 3832 - 3838 (2012)

A novel bipolar host material 9-(4,6-dip...

Dendritic bipolar main body material taking triazine as central core, and preparation method and application of dendritic bipolar main body material in organic electroluminescent device

-

, (2020/08/26)

The invention provides a compound with a...

Compound taking spirofluorene anthrone as core, preparation method and applications thereof

-

Paragraph 0089; 0091-0092; 0096; 0109; 0111, (2020/03/09)

The invention relates to a compound taki...

Boron-nitrogen heteropolyaromatic ring compound and application thereof

-

, (2020/08/29)

The invention relates to the technical f...

Organic compound and application thereof, and organic electroluminescent device

-

Paragraph 0112-0114, (2020/02/14)

The invention relates to the field of or...

1060735-14-9 Process route

3-bromo-9H-carbazole
1592-95-6

3-bromo-9H-carbazole

9-phenyl-3-(4,4,5,5-tetramethyl-1,3,2-dioxaborolane-2-yl)-9H-carbazole
1126522-69-7

9-phenyl-3-(4,4,5,5-tetramethyl-1,3,2-dioxaborolane-2-yl)-9H-carbazole

9-phenyl-3,3'-bicarbazole
1060735-14-9

9-phenyl-3,3'-bicarbazole

Conditions
Conditions Yield
With dicyclohexyl-(2',6'-dimethoxybiphenyl-2-yl)-phosphane; potassium phosphate; tris-(dibenzylideneacetone)dipalladium(0); In water; toluene; for 5h; Inert atmosphere; Reflux;
87%
With (1,1'-bis(diphenylphosphino)ferrocene)palladium(II) dichloride; potassium acetate; In 1,4-dioxane; for 4h; Inert atmosphere; Reflux;
80%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; at 80 ℃; for 24h; Inert atmosphere;
77%
With tetrakis(triphenylphosphine) palladium(0); sodium hydroxide; In tetrahydrofuran; water; at 80 ℃; for 12h; Inert atmosphere;
75%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; toluene; for 12h; Inert atmosphere; Reflux;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; toluene; for 12h; Reflux;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; for 12h; Inert atmosphere; Reflux;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; toluene; at 120 ℃; for 12h; Inert atmosphere;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; toluene; at 120 ℃; for 12h; Inert atmosphere;
68%
3-bromo-9H-carbazole; 9-phenyl-3-(4,4,5,5-tetramethyl-1,3,2-dioxaborolane-2-yl)-9H-carbazole; With tetrakis(triphenylphosphine) palladium(0); In tetrahydrofuran; toluene; Inert atmosphere;
With potassium carbonate; In tetrahydrofuran; water; toluene; at 120 ℃; for 12h;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; toluene; for 12h; Reflux; Inert atmosphere;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In tetrahydrofuran; water; for 12h; Inert atmosphere; Reflux;
68%
With tetrakis(triphenylphosphine) palladium(0); potassium carbonate; In 1,4-dioxane; water; at 120 ℃; for 5h; Reflux;
62%
With potassium carbonate; tetrakis(triphenylphosphine) palladium(0); In ethanol; toluene; at 74 - 80 ℃; for 5h; Inert atmosphere;
32.7%
3-iodocarbazole
16807-13-9

3-iodocarbazole

9-phenyl-3-(4,4,5,5-tetramethyl-1,3,2-dioxaborolane-2-yl)-9H-carbazole
1126522-69-7

9-phenyl-3-(4,4,5,5-tetramethyl-1,3,2-dioxaborolane-2-yl)-9H-carbazole

9-phenyl-3,3'-bicarbazole
1060735-14-9

9-phenyl-3,3'-bicarbazole

Conditions
Conditions Yield
With potassium phosphate; tetrakis(triphenylphosphine) palladium(0); In 1,4-dioxane; at 85 ℃; for 48h; Inert atmosphere;
74%
With potassium phosphate; tetrakis(triphenylphosphine) palladium(0); In 1,4-dioxane; at 85 ℃; for 48h; Inert atmosphere;
74%

1060735-14-9 Upstream products

  • 854952-58-2
    854952-58-2

    N-phenyl-9H-carbazol-3-boronic acid

  • 1592-95-6
    1592-95-6

    3-bromo-9H-carbazole

  • 86-74-8
    86-74-8

    9H-carbazole

  • 108-86-1
    108-86-1

    bromobenzene

1060735-14-9 Downstream products

  • 1060735-15-0
    1060735-15-0

    9-phenyl-9'-[4-(10-phenyl-9-anthryl)phenyl]-3,3'-bi(9H-carbazole)

  • 1245801-46-0
    1245801-46-0

    9-phenyl-9'-[4-(5-phenyl-1,3,4-oxadiazole-2-yl)phenyl]-3,3'-bi(9H-carbazole)

  • 1245801-43-7
    1245801-43-7

    9-phenyl-9'-[4-(3-phenylquinoxalin-2-yl)phenyl]-3,3'-bi(9H-carbazol)

  • 1150-62-5
    1150-62-5

    N-phenylcarbazole
